10 People Cabin Accommodation Suction Dredger Ship For River Sea Water Dredging Purpose

Suction Dredger Ship Description:

A Suction Dredger Ship is an essential piece of equipment in marine construction and dredging projects. Designed to efficiently remove sediment, debris, and other materials from underwater areas, this cutter suction dredger ship is a powerful tool for maintaining waterways and ports.

One of the key specifications of this cutter suction dredger ship is its draught, which ranges from 0.8 to 1.8 meters. This allows the dredger to operate in a variety of water depths, making it versatile for different dredging tasks. Constructed with durable marine steel, the cutter suction dredger ship is built to withstand the harsh conditions of marine environments, ensuring longevity and reliability.

The suction dredger ship we produce is self-propelled or non self-propelled,portable cutter suction dredger. The hull uses dismantle and box-like structure, Its dismantle type can be assembly at working place easily and be transported by road, railway and container accordingly, convenient in installation and working place moving from one to another. The power system can be designed to electric system or diesel engine driving system according to customers’ requirements.

The suction dredger ship design, construction, quality inspection is according to the standards and regulations of CCS. The suction dredger ship steel plates are CCSB plates which meet the requirements of CCS.

The welders are skillful and experienced and certified under the regulations of CCS.

Anti-corrosion paints material are marine use under the requirements of CCS.

The installation concentricity of diesel engine is less than 0.05mm.

-----The diesel engine brand is Cummins or Mitsubishi, which technology is from America and Germany.

  ------The pump brand is Kinda which technology is from Australia Warman.

  ------The gearbox is China famous brand Hangzhou Qianjin Advance Gearbox.

  ------The hydraulic system brand is Rexroth which technology is from Germany,

  ------The PLC system is from Germany SIEMENS.

  ------The bushes are from Japan NSK.

  ------The sealings brand is Parker from America.

Suction Dredger Ship Features:

• Product Name: Suction Dredger Ship
• Purpose: River Sea Water Dredging
• Dredging Method: Cutter Suction
• Draught: 0.8-1.8m
• Color: Customized
• Power Type: Diesel

Suction Dredger Ship Technical Parameters:

Suction Dredger Ship Applications:

Jin Meng's suction dredger ship, model JMD550, is a versatile and powerful vessel designed for a wide range of dredging applications. With its origin in China, this dredger is built to handle various dredging scenarios efficiently and effectively.

The JMD550 suction dredger ship is perfect for dredging projects in locations with a draft of 1.2m, making it suitable for both shallow and moderately deep waters. Its middle size allows for easy maneuverability while still providing ample capacity for dredging operations.

Equipped with a pump capacity of 3500-4000m3/h, the Jin Meng dredger ship is capable of handling large volumes of sediment and debris with ease.

The hull of suction dredger ship is composed by five pontoons, including one main pontoon and four side pontoons. The pontoons are full steel welding and are combined together by specially designed connecting pieces for convenient dismantle and assembly. All main parts of suction dredger ship can be dismantled easily for transportation by sea, railway or road.

The suction dredger ship is equipped with one diesel engine driving dredge pump.

One harbor generator is equipped on the deck of suction dredger ship.

Suction Dredger Ship Customization:

Product Customization Services for the Suction Dredger Ship:

Brand Name: Jin Meng

Model Number: JMD550

Place Of Origin: China

The suction dredger ship can be custom made according to customers’ requirements:

1. Anchor booms installation

2. Spud carriage

3. Suction dredger ship position of 5 anchors.

4. Hydraulic driving for spud flat down(to pass and transport on water safely).

5. Make the suction dredger ship with extra dredging pump underwater to deepen dredging depth for 20-30m underwater and slurry concentration is more than 30%.

6. Make the suction dredger ship with booster station to further the discharge distance.

Suction Dredger Ship Overseas Services:

The Product Technical Support and Services for the Suction Dredger Ship product include:

- On-site installation and commissioning

- Regular maintenance and repair services

- Operator training and technical assistance

- Spare parts supply and management

- Performance optimization and upgrades
