English
| Place of Origin: | China |
|---|---|
| Brand Name: | JIN MENG |
| Certification: | ISO9001 |
| Model Number: | JMD550 |
| Minimum Order Quantity: | 1 set |
| Price: | $300000-$800000 |
| Packaging Details: | Bulk |
| Delivery Time: | 30days |
| Payment Terms: | T/T |
| Supply Ability: | 10sets/year |
| Solid Capacity: | 700m3/h | Product Type: | River Dredger |
|---|---|---|---|
| Suction Pipe Diameter: | 600mm | Model: | JMD550 |
| Cutter Head Power: | 200KW Or Customized | Discharge Pipe Diameter: | 550mm |
| Discharge Distance: | 2500m | Spud Length: | 21m |
| Power: | 1662KW | Application: | River Dredging |
| Highlight: | Newly river dredging equipment,15m river dredging equipment,15m cutter head dredge |
||
| Attribute | Value |
|---|---|
| Solid Capacity | 700m³/h |
| Product Type | River dredger |
| Suction Pipe Diameter | 600mm |
| Model | JMD550 |
| Cutter Head Power | 200KW or customized |
| Discharge Pipe Diameter | 550mm |
| Discharge Distance | 2500m |
| Spud Length | 21m |
| Power | 1662KW |
| Application | River Dredging |
Weifang Jin Meng Dredger Co.,Ltd. located in Qingzhou, Weifang City, is a leading manufacturer and supplier of cutter suction river dredgers since 2000. Our products are competitively priced and widely used across Africa, the Middle East, Southeast Asia, South America, and the United States.
Recognized for our technical expertise, high-quality dredgers, and excellent after-sales service, we have established import/export departments, research institutes, and international service offices to better serve our customers.
Our company features:
The JMD550 Cutter Suction River Dredger features:
| Dredging Pump | Discharge pipe diameter: 550mm |
| Head | 65m |
| Max. Working Capacity | 900m³/h |
| Discharge Distance | 3000m |
| Dredging Depth | 14m |
| Diesel Engine | 1306KW (Cummins) |
| Hydraulic Auxiliary Engine | 336KW (Cummins) |
| Emergency Generator | 20KW (WEICHAI) |
| Total Power | 1662KW |
| Oil Consumption | 250L/H |
| Hull Dimensions | LOA×W×D: 42m×7.5m×2.0m |
| Hydraulic System | VICKERS America (Joint-venture) |
| Hydraulic Motor | Italy SAI technology (Joint-venture) |
| Valves | REXROTH Germany (Joint-venture) |
| Operating System | SIEMENS PLC (Imported from Germany) |
| Ladder Winch Tension | 120KN |
| Swing Winch Tension | 120KN |
| Cutter Head | Crown-like Φ1800mm, Power: 200KW |
