| Place of Origin: | China |
|---|---|
| Brand Name: | JIN MENG |
| Certification: | ISO9001 |
| Model Number: | JMD500 |
| Minimum Order Quantity: | 1 set |
| Price: | $500000-$800000 |
| Packaging Details: | Bulk |
| Delivery Time: | 30days |
| Payment Terms: | T/T |
| Supply Ability: | 10sets/year |
| Name: | Sea Dredging Cutter Dredger | Type: | Cutter Suction Dredger |
|---|---|---|---|
| Fuel Consumption: | 183liters/hour | Pump Type: | Centrifugal |
| Cutter Head Power: | 200kW | Cutter Head Diameter: | 1800mm |
| Dredging Capacity: | Up To 600m3/h | Dredging Depth: | Up To 14 Meters |
| Spud Diameter: | 300-600mm | Power Source: | Diesel Engine |
| Highlight: | 3500m3 cutter dredger,3500m3 cutter suction dredger,20inch cutter dredger |
||
| Name | Sea Dredging Cutter Dredger |
| Type | Cutter suction dredger |
| Fuel Consumption | 183 liters/hour |
| Pump Type | Centrifugal |
| Cutter Head Power | 200kW |
| Cutter Head Diameter | 1800mm |
| Dredging Capacity | Up to 600m³/h |
| Dredging Depth | Up to 14 meters |
| Spud Diameter | 300-600mm |
| Power Source | Diesel engine |
| Dredging Pump | WARMAN |
| Discharge Pipe Diameter | 500mm |
| Head | 65m |
| Max. Working Capacity | 700m³/h |
| Discharge Distance | 2500m |
| Dredging Depth | 14m |
| Diesel Engine | 895KW Cummins |
| Hydraulic Auxiliary Engine | 336KW Cummins |
| Emergency Generator | 20KW WEICHAI |
| Total Power | 1213KW |
| Oil Consumption | 183L/H |
| Hull Dimensions (L×W×D) | 42m × 7.5m × 2.0m |
| Hydraulic System Components | VICKERS (USA), SAI (Italy), REXROTH (Germany) |
| Operating System | SIEMENS PLC (Germany) |
| Cutter Head | Φ1800mm Crown-like, 200KW Power |
