| Place of Origin: | China |
|---|---|
| Brand Name: | JIN MENG |
| Certification: | ISO9001 |
| Model Number: | JMD250 |
| Minimum Order Quantity: | 1set |
| Price: | $90000-$200000 |
| Packaging Details: | Containers |
| Delivery Time: | 60days |
| Payment Terms: | T/T |
| Supply Ability: | 20sets/year |
| Name: | Water Cleaning Small Dredging Ship | Type: | Small Cutter Suction Dredger |
|---|---|---|---|
| Hull Material: | Marine Steel | Cutter Diameter: | 0.8 Meters |
| Application: | Water Dredging | Spud Length: | 12meters |
| Crew Capacity: | 6-8 Persons | Dredging Method: | Suction Or Cutter Suction |
| Draft: | 0.8 Meters | Dredging Depth: | 6-8meters |
| Highlight: | 550m3 csd dredger,550m3 dredging ship,water csd dredger |
||
| Attribute | Value |
|---|---|
| Name | Water Cleaning Small Dredging Ship |
| Type | Small cutter suction dredger |
| Hull Material | Marine Steel |
| Cutter Diameter | 0.8 meters |
| Application | Water Dredging |
| Spud Length | 12 meters |
| Crew Capacity | 6-8 persons |
| Dredging Method | Suction or Cutter suction |
| Draft | 0.8 meters |
| Dredging Depth | 6-8 meters |
Weifang Jin Meng Dredger Co., Ltd. is a professional manufacturer of water cleaning dredging ships with:
| Component | Specification |
|---|---|
| Dredging Pump | Dia. Discharge pipe: 250mm, Head: 35m, Capacity: 120m³/h |
| Discharge Distance | 800m |
| Diesel Engine | 150KW YUCHAI |
| Generator | 10KW WEICHAI |
| Total Power | 160KW |
| Oil Consumption | 24L/H |
| Hull Dimensions | 16m × 4.72m × 1.26m (LOA × W × D) |
| Hydraulic System | VICKERS (USA), SAI (Italy), REXROTH (Germany) |
| Operating System | SIEMENS PLC (Germany) |
| Cutter Head | Φ900mm, 30KW power |
For more details about our water cleaning dredging ships, please contact Weifang Jin Meng Dredger Co., Ltd.
Visit our factory to see our manufacturing process and discuss your specific dredging requirements.
