612HP Dredging Ship Cutter Suction Dredger Up To1200 Cubic Meters Per Hour Dredging Capacity

Heavy Dredging Ship Description:

A cutter suction dredging ship is a powerful vessel designed for various dredging operations in water bodies. This type of dredger is equipped with a cutter head that can loosen and remove hard materials, making it ideal for projects where precision and efficiency are crucial.

The cutter suction dredging ship is equipped with either a GPS or DGPS navigation system, ensuring accurate positioning and efficient dredging operations. This advanced navigation system allows the vessel to maintain precise control over its movements, making it suitable for dredging in challenging environments.

Cutter Head

There are total 5 blades and 8 teeth on each blade, so the total No. Of cutter teeth of cutter head is 40, and material of the teeth is high Manganese alloy which is wear-resistant.

Cutter bearing is changed to heavy-duty type, which is able to withstand greater overload and longer the service life.

 Shijiazhuang Pump

The material of the pump flowing through components is Cr 27, high wear-resistant alloy which can prolong the pump service life, and the shaft sealing is packing sealing which is easy to maintain, and anti-friction bearings are from Japan NSK.

 Mitsubishi Engine

-----Economical investment cost and low operating costs.

-----High energy conversion rate

-----Long cycle maintenance to save further cost.

-----High standard of safe and reliable control and monitoring implementation

-----The ideal combustion, and at the same time to protect engine.

Hydraulic System

-----Hydraulic valves is Rexroth of Germany.

-----Hydraulic pump is Vickers of America

-----Control system is PLC SIEMENS of Germany.

Key point: Hydraulic oil pipes made by pipe bending machine to avoid extra weld points, which can keep the whole system stability. When the oil pump finish, should be acid packing and phosphating treatment to keep whole system clean.

Engine Room

Arrangement in the engine room

Main engine Auxiliary engine

Dredging pump Generator

Hydraulic system Emergency generator

Electric distribution cabinet and Monitors

The space is enough and easy for maintain.

Design__Cutter suction dredging ship design meets the requirements and regulations of CCS, BV and ABS , which are belonging to IACS.

The technology refer to Holland IHC, and dredging ship can be custom made according to customers' requirements.

Chief engineer Gan attended the “Local cutter dredger design study on IHC Beaver” in 2000.

Steel plate__ Raw material is marine use material which meets the requirements of CCS., and all plates are under sand blasting process.

Hydraulic system__Hydraulic oil pipes made by pipe bending machine to decrease the welding points so that can keep system stability. When the oil pipe finish, should be acid picking and  phosphating treatment to keep whole system clean and stability.

Dredging pump__flow passage components use High wear resistant alloy Cr27 to prolonged the pump service life, pump shaft seal use packing seal which is easy to maintain , and anti-friction bearings are from Japanese brand NSK.

Dredging Ship Features:

• Product Name: Dredging Ship
• Type: Cutter Suction Dredger
• Spud Length: 21m
• Control: SIEMENS PLC
• Size and condition: Large And New
• Discharge Distance: 3 Kilometers

JMD650 Dredging Ship Technical Parameters:

Dredging Ship Applications:

A dredging ship like the Jin Meng JMD650 is a versatile and powerful vessel that can be utilized in various product application occasions and scenarios due to its advanced features and capabilities.

Here are some of the key product application occasions and scenarios for the Jin Meng JMD650 dredging ship:

1. Port Construction: The JMD650 is ideal for dredging operations in ports to maintain navigational channels, berths, and terminals, ensuring safe and efficient maritime activities.

2. Land Reclamation: This dredging ship can be used to reclaim land from the sea, creating new areas for development and infrastructure projects.

3. Channel Dredging: The JMD650 is perfect for dredging and maintaining waterways, rivers, and channels to prevent flooding and improve water flow.

4. Beach Nourishment: With its high discharge distance of 3 kilometers, this dredging ship is suitable for replenishing and restoring eroded beaches with sand and sediment.

5. Environmental Remediation: The cutter suction dredger type of the JMD650 is effective for cleaning up contaminated sediments in rivers, lakes, and coastal areas.

6. Underwater Mining: This dredging ship can be used for extracting minerals and resources from the seabed with precision and efficiency.

7. Infrastructure Maintenance: The JMD650 is essential for maintaining and deepening water infrastructure such as dams, reservoirs, and irrigation canals.

8. Oil and Gas Industry: With its powerful cutter head and spud length of 21 meters, this dredging ship is valuable for offshore oil and gas exploration and extraction projects.

Overall, the Jin Meng JMD650 dredging ship from China offers a reliable and high-performance solution for a wide range of dredging applications, making it a preferred choice for customers worldwide.

The sand dredging ship working process is as following: the cutter head cut the sand underwater to mixture of slurry, then through dredging pump to the pipeline; at the end of the slurry will be discharged by pipeline on land to the required place.

Functions of dredging ship: river dredging, desilting, reclamation for channels and land, especially for sand dredging in river, salty water or peaciful sea.

Dredging Ship Customization:

Customize your suction dredging ship with our Product Customization Services for the Jin Meng Dredging Ship.

Brand Name: Jin Meng

Model Number: JMD650

Place Of Origin: China

Certification: ISO

Minimum Order Quantity: 1 Set

Price: $1000000-$1400000

Packaging Details: Bulk

Delivery Time: 100 days

Payment Terms: TT

Supply Ability: 10 sets/year

Discharge Distance: 3 Kilometers

Dredging Capacity: Up To 1200 Cubic Meters Per Hour

Type: Cutter Suction Dredger

Cutter Head Power: 612HP

Driver Power: Diesel

Customize your dredging ship today to meet your specific requirements and enhance its capabilities as a dredger ship.

Dredging Ship Overseas Services:

The Dredging Ship product comes with comprehensive Product Technical Support and Services to ensure smooth operation and maintenance. Our team of experts is available to assist with any technical issues, troubleshooting, and guidance on optimal use of the equipment. Additionally, we offer regular maintenance services, spare parts availability, and training programs for the crew to enhance their skills and efficiency.

Dredging Ship Packing and Shipping:

Product Name: Dredging Ship

Description: Our state-of-the-art Dredging Ship is designed to efficiently remove sediment and debris from water bodies.

Packaging: The Dredging Ship will be carefully packed in a sturdy wooden crate to ensure safe transportation.

Shipping: We offer reliable shipping services to deliver the Dredging Ship to your location. Shipping costs may vary based on the destination.

Weifang Jin Meng Dredger Company Factory and Workshop

JMD650 Dredging Ship for River Sand Dredging in Nigeria

JMD650 Dredging Ship Assembly and Training in Working Site

Dredging Ship Newly Made in Stock, Welcome visit for more details
