| Place of Origin: | China |
|---|---|
| Brand Name: | JIN MENG |
| Certification: | ISO9001 |
| Model Number: | JMD250 |
| Minimum Order Quantity: | 1 set |
| Price: | $100000-$200000 |
| Packaging Details: | Containers |
| Delivery Time: | 60days |
| Payment Terms: | T/T |
| Supply Ability: | 20sets/year |
| Name: | Cutter Suction Small Dredger | Type: | Small Cutter Suction Dredger |
|---|---|---|---|
| Cutter Head Power: | 30 KW | Material: | Marine Steel |
| Suction Pipe Diameter: | 300 Mm | Maximum Dredging Depth: | 10 Meters |
| Power Source: | Diesel | Discharge Pipe Diameter: | 250 Mm |
| Dredging Capacity: | 100 Cubic Meters Per Hour | Fuel Consumption: | 24 Liters Per Hour |
| Highlight: | Lake Cleaning Machine 30kW,dredger cutter suction 100M3/h,small dredger cutter suction |
||
| Attribute | Value |
|---|---|
| Name | Cutter suction small dredger |
| Type | Small cutter suction dredger |
| Cutter Head Power | 30 kW |
| Material | Marine Steel |
| Suction Pipe Diameter | 300 mm |
| Maximum Dredging Depth | 10 meters |
| Power Source | Diesel |
| Discharge Pipe Diameter | 250 mm |
| Dredging Capacity | 100 cubic meters per hour |
| Fuel Consumption | 24 liters per hour |
| JMD250 Cutter suction small dredger | |
| Dredging Pump | Dia. Discharge pipe: 250mm |
| Head | 35m |
| Max. Working capacity | 120m3/h |
| Discharge distance | 800m |
| Dredging depth | 6m |
| Diesel Engine | 150KW | YUCHAI |
| Generator | 10KW | WEICHAI |
| Total power | 160KW |
| Oil Consumption | 24L/H |
| Hull Dimension | LOA*W*D: 16m×4.72m×1.26m |
| Hydraulic system | VICKERS America (Joint-venture) |
| Hydraulic Motor | Italy SAI technology(Joint-venture) |
| Valves | REXROTH Germany (Joint-venture) |
| Operating system | SIEMENS PLC(Imported from Germany) |
| Ladder winch | Tension: 25KN |
| Swing winch | Tension: 25KN |
| Cutter Head | Crown-like Φ900mm, Power: 30KW |
